Name: Plc Control System Downspout Machine Rain Water Roofing Gutter Making
Brand: Cangzhou Famous International Trading Co., Ltd
SKU: Rura spustowa
Price: 16,500.00 USD
Availability: InStock

Do domu > produkty > maszyna do formowania rolki rurowej >

Plc Control System Downspout Machine Rain Water Roofing Gutter Making

gutter making downspout machine

plc control system downspout machine

cold metal shaping downspout making machine

Miejsce pochodzenia:

Chiny kontynentalne

Nazwa handlowa:

CANGZHOU Famous

Orzecznictwo:

ISO CE

Numer modelu:

Rura spustowa

Skontaktuj się z nami

Poproś o wycenę

Szczegóły produktu

Nazwa produktu:

Rynna dachowa na wodę deszczową Maszyna do formowania rolek System sterowania PLC

Grubość materiału:

0,3-0,8 mm

Woltaż:

380V lub na życzenie klienta

System sterowania:

PLC

Typ:

Automatyczny

Gwarancja:

1 rok

Prędkość:

13-15 m/min

Materiał wałków:

45# stal

Podkreślić:

gutter making downspout machine

plc control system downspout machine

cold metal shaping downspout making machine

Warunki płatności i wysyłki

Minimalne zamówienie

1 zestaw

Cena

negotiable

Szczegóły pakowania

20' FLC

Czas dostawy

30 dni roboczych

Zasady płatności

L/C, T/T, D/A, D/P

Możliwość Supply

20 zestawów miesięcznie

Powiązane produkty

Mobile Vegetable Planting Trough Forming Machine with Hydraulic Motor 5.5KW and 8-15m/min Production Capacity for Greenhouse Vegetable Cultivation

Uzyskaj najlepszą cenę

Portable Gutter Roll Forming Machine with 500mm Feeding Width and 8-15m/min Production Capacity for Various Growing Methods

Uzyskaj najlepszą cenę

Mobile Greenhouse Vegetable Planting Trough Forming Machine With Quickly And Efficiently 5.5KW Hydraulic Motor

Uzyskaj najlepszą cenę

Portable Greenhouse Planting Trough Forming Machine with Hydraulic Motor 5.5KW 380V/50Hz/3Phase and 45# Steel Shaft

Uzyskaj najlepszą cenę

Skontaktuj się z nami

86-317-2016816

Skontaktuj się teraz

Opis produktu

Rain Water Roofing Gutter Making Rolling Roll Forming Machine PLC Control System

gutter cold roll forming machine can bend the roll formed pipe, and let the drainpipe and the bending connect to be the whole.The product after roll forming has long working time than the tranditional ppc pipe, and not aging. It can make the project more integrate, and help to enhance the image of the all project.

Rain gutter cold roll forming machine can bend the roll formed pipe, and let the drainpipe and the bending connect to be the whole.The product after roll forming has long working time than the tranditional ppc pipe, and not aging. It can make the project more integrate, and help to enhance the image of the all project

Specification

Material Type	Pre-painted steel coil & galvanized coils
Thickness	0.3-0.8mm
Yield strength	235Mpa.Q345Mpa, Q550Mpa
Roller material	Quenched and tempered treatment, hard chrome coated.05-0.07mm
Forming speed	About 15-20m/min
Speed adjusting mode	AC Frequency
Roller drive	Decelerating motor + Chain drive
Cutting mode	Hydraulic cutting
Cutter material	Cr12 mould steel
Length measurement	Encoder
Control mode	Panasonic or Delta PLC
Main motor	5.5KW
Hydraulic station motor	4KW

Guarantee

1.Guaranteed against malfunctions due to manufacturing defects for1 years after date of purchase except Electrical parts.

2. Repairs will not be performed even during the guarantee period in the follow circumstances

- Damage occurs due to a natural disaster

- Malfunction occurs due to user error

- Malfunction occurs due to modifications

- Malfunction occurs due to further movement or shipment after installation

Payment terms

40% in advance as down payment

60% is paid before the shipment is processed

Delivery

FOB: Tianjin Xingang Port

The Delivery Time: 30 days after the down payment is received.
