Name: Galvanized Roofing Tile Roll Forming Machine For Metal Roof Making Machine
Brand: Cangzhou Famous International Trading Co., Ltd
Price: 16,000.00 USD
Availability: InStock

Do domu > produkty > Maszyna do formowania rolek dachówek >

Galvanized Roofing Tile Roll Forming Machine For Metal Roof Making Machine

galvanized roofing tile roll forming machine

900mm roofing tile roll forming machine

hydraulic pressure tile roll forming machine

Miejsce pochodzenia:

CHINY

Nazwa handlowa:

cangzhou fms

Orzecznictwo:

CE,ISO

Skontaktuj się z nami

Poproś o wycenę

Szczegóły produktu

Nazwa produktu:

Maszyna do formowania rolek ocynkowanych dachówek Maszyna do produkcji dachów metalowych Cor

Metoda:

Ciśnienie hydrauliczne

Zdolność produkcyjna:

20 m/min

Woltaż:

380 V 50 Hz 3 fazy

Szerokość karmienia:

900 mm

Materiał rolki (twardy):

Cr12, podgrzewany i hartowany, polerowany

Wymiar (L*W*H):

8500*1400*1400Mm

Grubość rolki:

0,3-0,8 mm

Pod ramą:

350H wiązka, konstrukcja spawana

Materiał do wstępnego cięcia:

CR12MOV

Podkreślić:

galvanized roofing tile roll forming machine

900mm roofing tile roll forming machine

hydraulic pressure tile roll forming machine

Warunki płatności i wysyłki

Minimalne zamówienie

1 zestaw

Cena

negotiable

Szczegóły pakowania

Główna maszyna jest naga, skrzynka sterownicza komputera jest zapakowana w plastik.

Czas dostawy

30 dni

Zasady płatności

T/T, Western Union

Możliwość Supply

30 zestawów miesięcznie

Powiązane produkty

6m Automatic Stacker for Roof Sheet Roll Forming Machine

Uzyskaj najlepszą cenę

Wideo

the factory price for 0.3-0.8mm thickness Glazed Roof sheet forming machine

Uzyskaj najlepszą cenę

Wideo

2025 New Design for Glazed Roof Tile Roof Sheet Roll Forming Machine With 18 Rows

Uzyskaj najlepszą cenę

Wideo

4meter/Min Glazed Tile Roll Forming Machine With 18 Rows

Uzyskaj najlepszą cenę

Skontaktuj się z nami

86-317-2016816

Skontaktuj się teraz

Opis produktu

Galvanized Roofing Tile Roll Forming Machine Cor Metal Roof Making Machine

Galvanized Roofing Tile Roll Forming Machine Cor Metal Roof Making Machine.

CANGZHOU FAMOUS INTERNATIONAL TRADING CO., LTD is cal glazed tile forming machine ,c/z puline machine for light steel structure building ,floor deck forming machine sandwich

panel production line ,fast guardrail roll forming

line and various kind of full automatic cold bending

roll forming machine equipment.

we have approved certification of ce iso9001,the concept control everyone orocess and perfect all products is curved in everyone mind ,each machine.will be via load carrying test before leaving factory,problem machines will never be delivered to customer.

we are willing to promote the economic and technical,exchange with the word ,and do positive work to enhance the between people from different countries,we sincerely hope you and hand in hand ,create the glorious future altogether.

Specification

Roller station	16Steps
Under Frame	350H-beam, Welded structure
Shaft diameter(Solid)	70mm-0.01~-0.03(with key-way)
Shaft material(Hard)	High grade 45# steel,heated and quenched,cylindrical grinding,
Roller material(Hard)	Cr12,heated and Quenched,polishing
Bearing Type	Standard
Transmission Gear	Heat treatment
Motor Power	5.5KW(Lichao,Shanghai)
Forming Speed	0-20m/min(Non-Stop)
Hydraulic Cutting	Tracking Length To Cut
Pump power	5.5 KW
Hydraulic pressure	20 Mpa
Voltage Standard	380V/3Phases/50Hz
Cutting die	Cr12Mov, Quenched processed

Guarantee

1. Guaranteed against malfunctions due to manufacturing defects for1 years after date of purchase except Electrical parts.

2. Repairs will not be performed even during the guarantee period in the follow circumstances

- Damage occurs due to a natural disaster

- Malfunction occurs due to user error

- Malfunction occurs due to modifications

- Malfunction occurs due to further movement or shipment after installation

Payment terms

40% in advance as down payment

60% is paid before the shipment is processed

Delivery

FOB: Tianjin Xingang Port

The Delivery Time: 30 days after the down payment is received.
