Name: Metal Stud & Track Roll Former Machine With Punching
Brand: Cangzhou Famous International Trading Co., Ltd
SKU: Stój i śledź
Price: 40,500.00 USD
Availability: InStock

Do domu > produkty > Maszyna do tworzenia rolki z kołkami i ścieżkami >

Metal Stud & Track Roll Former Machine With Punching

Metal Stud Track Roll Former Machine

Metal Stud Track Roll Former

Punching stud roll forming machine

Miejsce pochodzenia:

Chiny kontynentalne

Nazwa handlowa:

FMS

Orzecznictwo:

ISO CE

Numer modelu:

Stój i śledź

Skontaktuj się z nami

Poproś o wycenę

Szczegóły produktu

Nazwa produktu:

Metalowa kołek i gąsienica Była rolka maszynowa z wykrawaniem

Wymiar (L*W*H):

5500mm*1000mm*1500mm

Surowiec:

Galvalume, ocynkowane

Prędkość pracy:

20 - 40 m/min

szerokości kołka:

3 1/2″, 5 1/2″

Miernik:

Wskaźnik 24-16

Moc silnika:

4KW

Zasilanie:

220 V 3 fazy 60 Hz

Profil:

Zgodnie z życzeniem klienta

Tor kołnierzowy:

3,6 i 5,6 x 2,125

Podkreślić:

Metal Stud Track Roll Former Machine

Metal Stud Track Roll Former

Punching stud roll forming machine

Warunki płatności i wysyłki

Minimalne zamówienie

1 zestaw

Cena

negotiable

Szczegóły pakowania

20' FLC

Czas dostawy

30 dni roboczych

Zasady płatności

L/C, T/T, D/A, D/P

Możliwość Supply

20 zestawów miesięcznie

Powiązane produkty

Wideo

Omega Profile Light Keel Steel Framing Top Hat Channel Roll Forming Machine

Uzyskaj najlepszą cenę

C89 Lgs Light Gauge Steel Roll Forming Machine For Villa House

Uzyskaj najlepszą cenę

Roller Fixer Guide Column CU stud for Long-lasting Roofing

Uzyskaj najlepszą cenę

Guide Column Roller Fixer Stud And Track Roll Forming Machine with 7.5KW Hydraulic Station Power and Plc S7-200 Control

Uzyskaj najlepszą cenę

Skontaktuj się z nami

86-317-2016816

Skontaktuj się teraz

Opis produktu

Metal Stud & Track Roll Former Machine Roll Former With Punching

The sMetal Stud & Track Roll Former Machine Roll Former With Punching for use in commercial and domestic buildings where it is necessary to provide strong non-load-bearing partitions.
There is a wide range of partition thickness available for heights of up to 12m. The system is economical and can be erected easily. When installing the system, it is advisable to use and electrically or battery-operated screw gun. It is necessary to ensure that electric cables can pass through the studs that are protected by grommets.

Specification

No.	Item	Description
1	Coil	Galvalume, Galvanized
2	Raw Material Thickness	0.4-0.6mm
3	Working Speed	20-40 m/min
4	Roller Station	12 Raws
5	Dimension (LWH)	5500 mm1000 mm1500 mm
6	Machine Weight	1500 KG
7	Electrical Control System	Delta PLC (can be customized)
8	Flange Track	3.6 & 5.6 x 2.125
9	Hydraulic Station Power	4 KW
10	Power Supply	220v 3 phase 60hz(can be customized)
11	Cutting Accuracy	±2 mm
12	gauge	24 gauge -16 gauge
13	Profile	as customer requested
14	Material of Roller	45# Steel Finish Machining, Plated Hard

Advantage

The metal system is accurate and solid, and will not move over time or with changes in temperature.
There is a wide range of stud widths from 50mm to 146mm to meet varying requirements.
It is a fast and clean system to erect that allows services to pass through easily.
All sections fit together easily and door frames are formed very simply.

Payment terms

30% in advance as down payment

70% is paid before the shipment is processed

Delivery

FOB: Tianjin Xingang Port

The Delivery Time: 30 days after the down payment is received.
