Name: Automatic Control Metal Deck Roll Forming Machine With 10 - 20m/Min
Brand: Cangzhou Famous International Trading Co., Ltd
SKU: Pokład podłogowy
Price: 26,500.00 USD
Availability: InStock

Do domu > produkty > Maszyna do formowania rolki podłogowej >

Automatic Control Metal Deck Roll Forming Machine With 10 - 20m/Min

Metal Deck Forming Machine 20m/Min

PLC Metal Deck Roll Forming Machine

20m/Min metal deck forming machine

Miejsce pochodzenia:

Chiny kontynentalne

Nazwa handlowa:

FMS

Orzecznictwo:

ISO CE

Numer modelu:

Pokład podłogowy

Skontaktuj się z nami

Poproś o wycenę

Szczegóły produktu

Nazwa produktu:

Automatyczna maszyna do formowania rolek metalowych z prędkością 10 - 20 m / min

Wymiar (L*W*H):

12*1,8*2,0

Materiał z ostrza:

CR12 wygaszone

Typ kontroli:

System PLC

Materiał wału:

Wysokiej jakości kute nr 45

Waga:

11500 kilogramów

Woltaż:

380 V 50 Hz 3 fazy

Zdolność produkcyjna:

15-20 m/min

Podkreślić:

Metal Deck Forming Machine 20m/Min

PLC Metal Deck Roll Forming Machine

20m/Min metal deck forming machine

Warunki płatności i wysyłki

Minimalne zamówienie

1 zestaw

Cena

negotiable

Szczegóły pakowania

40' FLC

Czas dostawy

30 dni roboczych

Zasady płatności

L/C, T/T, D/A, D/P

Możliwość Supply

20 zestawów miesięcznie

Powiązane produkty

Wideo

Cellular Composite Roofing Sheet Making Machine 3.0" Width 0.8-2.0MM Thickness

Uzyskaj najlepszą cenę

Wideo

13 Rows Roof Tile Roll Forming Machine For Tipo Teja Americana Normal Tile

Uzyskaj najlepszą cenę

Wideo

Decking Flooring Board 1.2mm Floor Tile Making Machine

Uzyskaj najlepszą cenę

Wideo

45 Steel Deck Roll Forming Machine Cold ±2mm Cutting Tolerance Excellent Performance

Uzyskaj najlepszą cenę

Skontaktuj się z nami

86-317-2016816

Skontaktuj się teraz

Opis produktu

Automatic Control Metal Deck Roll Forming Machine With 10 - 20m/Min

Products are widely used in power plants, power equipment companies, automotive exhibition halls, steel structure plants, cement tanks, steel structure offices, airport terminals, railway stations, stadiums, concert halls, large -scale supermarkets, logistics centers, Olympic venues sports sports Steel structure buildings such as venues

Specification

Customized Metal Deck Roll Forming Machine With 15 - 20m/Min
Dimensions	12.51.82.0m
Weight	About 10500kgs
Roller	26 Rows
Material of the Cutting Blade	Cr12, Quenched treatment 58℃-60℃
Rolling Materials	45# forging steel with chromium plate
Diameter of the Roller	Φ90mm
Main Structure of the Machine	450H beams
Side Panel of Machine	20mm
Chain	1 Inch
Motor Power	15Kw*2
Pump Station Motor	4Kw Lichao Brand
Productivity	10-15m/min
Thickness of the Plate	0.5-1.2mm
Length Tolerance	±2mm
Touch Screen	Delta
Voltage	380V 50Hz 3 phases or as customer's need
Drive Mode	Motor driver
Suitable to Process	GI/GL/PPGI/PPGL/Aluminum coils

Application

To meet the requirements of the rapid construction of the main steel structure, it can provide a firm operating platform in a short period of time, and can use multiple floors to lay pressure steel plates, and layered pouring concrete plate flowing water construction construction

Advantage

1: To meet the requirements of the rapid construction of the main steel structure, it can provide a firm operating platform in a short period of time. It can also use multiple floors to lay pressure steel plates and layered flowing water on the stratified concrete plate.
2: During the use stage, the tillers of the concrete floor are also increased the rigidity of the floor, which saves the amount of steel and concrete.
3: The surface pressure of the pressure plate makes the maximum binding force between the panel and the concrete, so that the two form the overall, with the ribs, so that the building's board system has a high -strength bearing capacity.
4: Under the cantilever conditions, the Loucheng board is only used as a permanent template. The length of the suspended length can be determined according to the section characteristics of the building. In order to prevent the cracking of the suspended board, it is necessary to match the negative tendon according to the design of the structural engineer at the branch.

Delivery

FOB: Tianjin Xingang Port

The Delivery Time: 30 days after the down payment is received.
